Jetta / jetbook9080brochure.jpg

Dimension
- 12.95" x 10.98" x 1.66" (329mm x 279mm x 42.3mm) for 14.1"

Weight
- 7.9lb/3.6kg for 14.1" TFT LCD/DVD, 8.3lb/3.8kg for 15.0" TFT LCD/DVD

CPU
- Intel Desktop P4 1.5G to 1.7Ghz or Northwood upgradeable
- On die 256KB(Willamette), 512KB(Northwood) L2 cache

Chipset
- Intel DT Brookdale (845), ICH2, Support 400Mhz Bus

Memory
- One SDRAM memory slot for 128/256/512 MB RAM.
- Support SDRAM 128MB, 256MB, 512MB module

FDD
- (built-in) 12.7mm, 1.44MB (Square type drive), Fixed type but easy installation at factory side

Optical device
- 12.7mm, 24x CD-ROM drive, 12.7mm, 8x DVD-ROM drive,
- 12.7mm CD-RW drive 8/8/24, 12.7mm DVD & CD-RW Combo

HDD
- 9.5mm, 2.5" HDD support with 20GB/30GB/40GB capacity, design for easy replaceable
- PCI Bus Master Enhanced IDE, Ultra DMA 100 support

Display
- 1024 x 768 XGA TFT color LCD, display area 14.1"/15.1"

Video Chip
- ATI M6-P, External 16MB VGA DDR RAM, Simultaneous display on LCD and CRT
- 3D Windows accelerator, Support 15/16/24bbp True Color on LCD & dual view
- Hardware expansion for high resolution LCD, Support TV-out

Audio
- 4299 AC97 Codec, Microphone-in and headphone-out

PCMCIA
- TI1420 Cardbus controller, one type III or two type II, PCI card bus, No ZV-Port support

Communication Modem: V.90/56K bps specification compliant and 14.4K bps Send/Receive Fax with MDC solution

LAN: 10/100M bps LAN with external INTEL PHY on board

Keyboard: 87/88/90 keys support with 101/102 key emulation

Pointing Device: Touch Pad with two buttons

I/O ports
- USB x 3 ports, High speed bi-directional parallel port, 25 pins, ECP/EPP
- One DDC2b compliant VGA port , 15 pins Microphone-in, Headphone-out jacks, DC-in jack
- RJ-11 jack for 56Kbps V.90 Modem, RJ-45 jack for 10/100MB Ethernet
- Kensington lock, TV-Out(S-Video), VR for volume control
- No PS/2 x 1, No Line in, No 1394 (ME reserved space), No Serial port, No IR

Speaker: Two stereo speakers

AC Adapter
- Universal AC adapter. 90-264V AC, 47-63HZ, 90W with 19V DC output

Battery
- 12 cell LI-ION of 18650 size battery pack w/ up to 87WH capacity
- 2.2hrs (@25 degree C and 35 degree C) operation time on main battery with Battery mark 4.0
3.0hrs for long life mode. Charging time 9 hrs (System on)

Software
- Phoenix BIOS, 512KB Flash BIOS ROM, Suspend to RAM/Disk, Various hot-keys for system control
- Operating System WinXP (Home/Pro)/W2K (with PC 01 LOGO, and K/B LOGO)
